Selecting the correct capacitor requires matching the capacitance value, voltage rating, and physical form factor to your specific application. Electrolytic kits are ideal for general electronics repair and DIY projects, offering a wide range of microfarad values. These kits typically include in-line or radial lead components suitable for power supplies and audio circuits.
For HVAC and motor applications, dual run capacitors are specialized components with specific terminal configurations. These units are rated for higher voltages and are designed to start and run AC motors. Understanding the difference between general-purpose electrolytic kits and specialized HVAC replacements ensures you choose the right component for your task.
Our 3 picks for different needs
BOJACK 24 Value 630pcs Electrolytic Kit
The 630-piece count provides a large inventory for technicians repairing multiple devices or building extensive projects.
Read the details
FOCSPROD 40+5uF CBB65 AC Capacitor
This 40+5uF capacitor is UL recognized and TUV Rheinland certified, meeting strict safety standards for AC motor applications.
Read the details
BOJACK 15 Type 600pcs Ceramic Capacitor Kit
The 10pF to 100nF range covers low capacitance values essential for high-frequency and data processing circuits.
Read the detailsAll products, in detail
ALLECIN 24 Value Electrolytic Capacitor Kit
This in-line aluminum electrolytic kit offers 24 different values ranging from 0.1uF to 1000uF. It supports voltage ratings of 10V, 16V, 25V, and 50V, making it suitable for a variety of electronic experiments. The capacitors feature long leads for positive polarity and short leads for negative.
The kit is designed for household appliances and DIY circuit boards, with packaging that facilitates easy storage and retrieval for hobbyists.
- Contains 24 different values from 0.1uF to 1000uF
- In-line aluminum electrolytic construction
BOJACK 24 Value 630pcs Electrolytic Kit
This assortment box includes 630 capacitors across 24 values, covering the range from 0.1uF to 1000uF. The capacitors are marked with values and voltage ratings of 10V, 16V, 25V, and 50V. They are housed in a plastic box with labeled compartments to prevent sliding. These high-precision capacitors operate from -40C to +105C with a 20% tolerance, suitable for power supplies, audio amplifiers, and repairs of TVs and game consoles.
- Total of 630 capacitors in 24 values
- Operating temperature range of -40C to +105C
BOJACK 45+5uF CBB65 Dual Run Capacitor
This circular CBB65 capacitor is designed for AC motor run or fan start applications. It features a 45+5uF rating with a 6% tolerance and 370V/440VAC voltage. The unit has three terminals labeled for the compressor motor, fan, and common line. It operates between -40C and +70C and is listed as a replacement for various model numbers including 97F9895 and 27L880, serving HVAC and condenser systems.
- 45+5uF dual run rating at 370V/440VAC
- Three terminals labeled Herm, Fan, and Common
BOJACK 35+5uF CBB65 Dual Run Capacitor
This dual run circular capacitor provides a 35+5uF rating with a 6% tolerance. It is rated for 370V/440VAC and features three terminals for the compressor, fan, and common line. The operating temperature range is -40C to +70C. This specific model is designed for AC motor run or fan start applications in HVAC systems, offering a distinct capacitance value compared to other dual run options in the lineup.
- 35+5uF dual run rating at 370V/440VAC
- Diameter of 1.97 inches and height of 4.14 inches
200PCS 15 Value Electrolytic Capacitor Kit
This kit contains 200 radial lead capacitors across 15 values from 0.1uF to 1000uF. It supports voltage ratings of 10V, 16V, 25V, and 50V. The capacitors feature clear polarity markings and are designed with low ESR and high ripple current resistance. They are suitable for smoothing, filtering, and timing circuits in power supplies and audio applications, organized in a labeled plastic storage box for easy access.
- 200 capacitors in 15 values with radial leads
- Low ESR and high ripple current resistance
Tnisesm 28 Value Electrolytic Capacitor Kit
This in-line aluminum electrolytic kit includes 28 different values ranging from 0.1uF to 4700uF. It supports voltage ratings of 10V, 16V, 25V, 35V, and 50V. The capacitors are designed for large capacity in a small size with low internal resistance. They operate from -40C to +105C with a 20% tolerance, making them suitable for household appliances and DIY circuit boards where higher capacitance values are required.
- 28 values ranging up to 4700uF
- Includes 35V voltage rating option
FOCSPROD 40+5uF CBB65 AC Capacitor
This UL recognized and TUV Rheinland certified capacitor is rated at 40+5uF with a 6% tolerance. It is designed for 370V/440VAC applications and features a 10,000 AFC safety rating. The round capacitor has a diameter of 50mm and a height of 125mm. It serves as a replacement for various HVAC models, including 97F9838 and 12786, and is backed by a lifetime warranty for long-term use in AC units and heat pumps.
- UL recognized and TUV Rheinland certified
- 40+5uF rating with 10,000 AFC safety rating
BOJACK 15 Type 600pcs Ceramic Capacitor Kit
This assortment kit contains 600 multilayer monolithic ceramic capacitors across 15 types. The values range from 10pF to 100nF, with each model represented by 40 pieces. The capacitors feature a 10% tolerance and are packed in a re-sealable plastic case. They offer excellent humidity resistance and miniature size, making them suitable for computers, data processing, telecommunication, and industrial control applications where small capacitance is needed.
- 600 capacitors in 15 types from 10pF to 100nF
- Multilayer monolithic ceramic construction
Head-to-Head Comparisons
BOJACK 630pcs vs 200PCS 15 Value Kit
The BOJACK 24 Value kit offers 630 capacitors, providing a larger inventory for extensive repair work. The 200PCS kit contains 15 values, which is a more compact selection for hobbyists who need fewer parts. Both kits cover the 0.1uF to 1000uF range with similar voltage ratings.
The BOJACK kit includes 24 values, offering more granularity in capacitance selection. The 200PCS kit focuses on 15 common values, which may be sufficient for basic projects. Choose the larger kit if you need a comprehensive stock, or the smaller kit for a starter collection.
BOJACK 45+5uF vs 35+5uF Dual Run
These two BOJACK dual run capacitors differ primarily in their main capacitance rating. The 45+5uF model is designed for motors requiring higher run capacitance, while the 35+5uF model serves applications with lower requirements. Both are rated for 370V/440VAC and feature the same three-terminal configuration. The 45+5uF unit has a diameter of 65mm, whereas the 35+5uF unit has a diameter of 1.97 inches.
You must select the unit that matches the original component's rating to ensure proper motor operation and safety.
ALLECIN 24 Value vs Tnisesm 28 Value
The Tnisesm kit offers 28 values extending up to 4700uF, providing higher capacitance options than the ALLECIN kit. The ALLECIN kit includes 24 values up to 1000uF, which covers most standard electronics needs. The Tnisesm kit also includes a 35V voltage rating, adding flexibility for higher voltage circuits.
Both kits use in-line aluminum electrolytic capacitors. If your projects require very high capacitance values, the Tnisesm kit is the better fit. For standard 10V to 50V applications, the ALLECIN kit provides a solid range of options.
Buying Guide
Capacitance Value and Tolerance
Capacitance is measured in farads, with most kits using microfarads (uF) or picofarads (pF). Electrolytic kits typically range from 0.1uF to 1000uF or higher. Ceramic kits cover smaller values like 10pF to 100nF. Tolerance indicates the acceptable deviation from the stated value, commonly 20% for electrolytic and 10% for ceramic.
Selecting the correct value is critical for circuit timing and filtering. Check your schematic or original component to match the required capacitance and tolerance for optimal performance.
Voltage Rating and Safety
The voltage rating indicates the maximum voltage a capacitor can safely handle. Electrolytic kits often include 10V, 16V, 25V, and 50V options. HVAC capacitors are rated for higher voltages, such as 370V or 440VAC. Always choose a capacitor with a voltage rating equal to or higher than your circuit's operating voltage.
Exceeding the rated voltage can cause failure. For HVAC applications, ensure the replacement matches the original voltage rating to maintain safety and compliance with electrical standards.
Form Factor and Lead Type
Capacitors come in different physical forms, including in-line and radial leads. In-line capacitors have two leads on the same side, while radial leads have two leads on the same end. The physical size and lead spacing must match your circuit board or device. Ceramic capacitors are typically smaller and used in high-frequency applications.
Electrolytic capacitors are larger and used for power filtering. Ensure the physical dimensions and lead type of the replacement capacitor fit the available space and mounting holes in your device.
Application Specifics: DIY vs HVAC
General electronics kits are suitable for DIY projects, repairs, and experiments. They offer a variety of values for different circuits. HVAC capacitors are specialized for motor starting and running. They have specific terminal configurations and safety certifications. Do not use a general electrolytic capacitor as a replacement for an HVAC dual run capacitor.
The voltage ratings and safety features are different. Match the application type to the capacitor design to ensure reliable and safe operation in your specific project or repair.
Frequently Asked Questions
Can I use a ceramic capacitor instead of an electrolytic one?
No, they serve different purposes. Ceramic capacitors are used for high-frequency filtering and small signal coupling. Electrolytic capacitors are used for power supply filtering and energy storage. They have different voltage ratings, polarities, and physical sizes. Always use the type specified in your schematic or original component to ensure circuit stability and safety.
What does the dual run rating mean on HVAC capacitors?
A dual run capacitor has two capacitance values, such as 45+5uF. The larger value is for the compressor motor, and the smaller value is for the fan motor. This allows one capacitor to serve both motors in an HVAC system. The terminals are labeled to indicate which motor each value serves.
Ensure the replacement matches the original dual run rating exactly.
How do I identify the polarity of an electrolytic capacitor?
Electrolytic capacitors are polarized. The negative terminal is usually marked with a stripe on the casing and indicated by the shorter lead. The positive terminal is the longer lead. Reversing the polarity can cause the capacitor to fail or explode. Always check the markings on the capacitor and your circuit board to ensure correct orientation during installation.
Are these capacitor kits suitable for professional repair work?
Yes, many kits are designed for professional use. They offer high-precision components with clear markings and stable performance. The large quantity in some kits allows technicians to maintain a stock of common values. However, for critical applications like HVAC, ensure the specific replacement part matches the original model and safety certifications to maintain compliance and reliability.
