Selecting the right dip switch depends on the number of positions required for your circuit and the specific development board you are using. Whether you are building a simple breadboard prototype or a complex PCB, the position count and pitch must match your design requirements.
This comparison looks at eight different dip switch options, ranging from single-position switches to 12-position configurations. We examine the quantity, color, and specific position counts included in each kit to help you find the right fit for your electronics projects.
Our pick: EGSCST 41-Piece Blue Double Row Kit. This blue kit covers every position count from 1 to 10, ideal for users who need a wide range of configurations without buying separate packs.
Our 3 picks for different needs
EGSCST 41-Piece Blue Double Row Kit
This blue kit covers every position count from 1 to 10, ideal for users who need a wide range of configurations without buying separate packs.
Read the details
10-Piece 4-Position Red Switch Pack
Designed for Arduino, ESP32, and Raspberry Pi, this pack is a direct fit for makers configuring hardware settings on popular dev boards.
Read the details
40-Piece Red Assorted Kit
Including 12-position switches, this red kit is suitable for complex circuits that require more than 10 positions for address selection.
Read the detailsAll products, in detail
EGSCST 41-Piece Blue Double Row Kit
This assortment kit provides 41 blue slide-type dip switches covering positions 1 through 10. It is designed for DIY electronics, industrial control panels, and educational lab setups. The kit includes every position count from 1 to 10, which helps eliminate the hassle of incomplete configurations for complex circuits.
All switches are packed in pressure-resistant plastic boxes for easy organization and quick access during project work.
- Includes 41 switches covering 1 to 10 positions
- Features 2.54mm pitch and 24V DC 25mA switching rating
EGSCST 41-Piece Red Double Row Kit
This red-colored assortment kit offers 41 slide-type dip switches spanning positions 1 through 10. It targets the same applications as its blue counterpart, including DIY electronics and educational labs. The set includes every position count from 1 to 10, ensuring you have the right switch for various circuit configurations.
The switches are stored in pressure-resistant plastic boxes, making them easy to find and use quickly in a workshop or classroom environment.
- Red color variant with 41 total switches
- Covers 1 to 10 positions with 2.54mm pitch
Dahszhi 20-Piece 4-Position Pack
This pack contains 20 double-row dip switches, each with 4 positions and 8 pins. It is a slide-type switch with a 2.54mm pitch, suitable for circuit boards, breadboards, and PCB projects. The switches are designed to function as toggle or on/off switches for various electronic projects.
The listing specifies a non-switching rating of 100mA DC 50V and a switching rating of 25mA DC 24V, providing clear electrical parameters for low-power applications.
- 20 switches with 4 positions and 8 pins
- Non-switching rating of 100mA DC 50V
10-Piece 4-Position Red Switch Pack
This pack includes 10 red 4-way dip switches, ideal for configuring hardware settings, address selection, and signal routing. It is designed for compatibility with popular development boards like Arduino, ESP32, ESP8266, and Raspberry Pi. Each switch features visible ON/OFF markings and smooth toggling for easy manual configuration.
The switches are built with quality materials for long-term use and are suitable for classrooms, workshops, or personal electronics labs.
- 10 red switches with clear ON/OFF markings
- Designed for Arduino, ESP32, and Raspberry Pi
40-Piece Red Assorted Kit
This kit contains 40 red double-row dip switches in eight different position counts: 1, 2, 3, 4, 6, 8, 10, and 12. It includes 5 pieces of each position type, providing a balanced assortment for various projects. The switches are slide-type with a 2.54mm pitch and are made of durable plastic and metal.
They come with a plastic box for storage, keeping the toggle switches well organized for easy retrieval during circuit building.
- 40 switches in 8 position counts (1-12)
- Includes 5 pieces of each position type
Juasky 40-Piece 1-4 Position Kit
This kit includes 40 slide-type dip switches, specifically covering 1, 2, 3, and 4 positions. It contains 10 pieces of each position count, totaling 40 switches packaged in boxes for classification. The switches have a 2.54mm pitch and are made of strong plastic and metal.
They are suitable for breadboards, circuit boards, and PCB projects, as well as products used in data processing and communication applications.
- 40 switches covering 1 to 4 positions
- 10 pieces of each position count
uxcell 20-Piece Black 1-8 Position Kit
This pack offers 20 black double-row dip switches, each with 8 positions and 16 pins. It is a 1/2/3/4/5/6/7/8 way 2-row dip encode switch with a 2.54mm pitch. The switches are constructed with durable plastic and metal materials, designed for an extended lifespan. They are commonly used to customize the behavior of electronic devices for specific situations and are widely used in circuit boards and breadboards.
- 20 black switches with 8 positions
- 2-row 16-pin configuration with 2.54mm pitch
Dahszhi 10-Piece 8-Position Pack
This pack contains 10 double-row dip switches, each with 8 positions and 16 pins. It features a 2.54mm pitch and a total size of 2.2 x 1 x 1 cm. The switches are designed for use in circuit boards and breadboards. The listing specifies a non-switching rating of 100mA DC 50V and a switching rating of 25mA DC 24V, making them suitable for low-power control applications in various electronic projects.
- 10 switches with 8 positions and 16 pins
- Dimensions of 2.2 x 1 x 1 cm
Head-to-Head Comparisons
EGSCST Blue vs Red: Color Preference
The EGSCST blue and red kits are identical in their technical specifications, both offering 41 switches covering positions 1 through 10 with a 2.54mm pitch. The primary difference is the color of the switch body. If you prefer blue components for your project aesthetic or to distinguish them from other red switches in your inventory, the blue kit is the choice.
Conversely, if you already have a collection of red switches or prefer that color for visibility, the red kit is the better fit. Both are packed in pressure-resistant plastic boxes for easy storage.
Wide Assortment vs Focused Low-Position Kit
The 40-piece red kit offers a broader range of position counts, including 6, 8, 10, and 12 positions, with 5 pieces of each. This makes it suitable for projects that might require higher position counts. In contrast, the Juasky 40-piece kit focuses exclusively on 1, 2, 3, and 4 positions, providing 10 pieces of each.
If your projects primarily involve simple on/off or 4-way configurations, the Juasky kit provides more quantity of the specific switches you need. If you anticipate needing 8 or 12-position switches, the red assortment is the more versatile option.
Dahszhi 4-Position vs 8-Position Packs
Both Dahszhi packs feature a 2.54mm pitch and similar electrical ratings, but they differ in position count and quantity. The 20-piece pack contains 4-position switches, while the 10-piece pack contains 8-position switches. If you are building a circuit that requires 8-way configuration, the 8-position pack is the necessary choice, though it comes in a smaller quantity.
If you need 4-position switches for simpler configurations, the 20-piece pack offers more units per pack. Choose based on the specific position count required by your circuit design.
Buying Guide
Position Count Requirements
The number of positions on a dip switch determines how many binary states it can represent. A 4-position switch can represent 16 states, while an 8-position switch can represent 256 states. Check your circuit design or development board documentation to determine the exact position count required.
Buying a kit with the wrong position count will result in incompatible switches that cannot be soldered or plugged into your PCB or breadboard.
Pitch and Compatibility
All listed switches feature a 2.54mm pitch, which is the standard spacing for most DIP switches and compatible with standard breadboards and PCBs. Ensure that your PCB or breadboard has the correct hole spacing to accommodate the 2.54mm pitch. If you are working with a non-standard pitch, these switches will not fit.
The 2.54mm pitch is widely used in electronics, making these switches compatible with a wide range of projects.
Quantity and Storage
Consider how many switches you will need for your project. Some kits offer 10 pieces, while others provide 20 or 40. If you are a student or hobbyist working on multiple projects, a larger kit may be more convenient. Several listed kits, such as the EGSCST, Dahszhi, and Juasky assortments, include plastic boxes to keep the switches organized.
This is important for maintaining an orderly workspace and preventing loss of small components.
Color and Visibility
The color of the switch body can affect visibility on your PCB or breadboard. Red and blue switches are common, while black switches may be less visible on dark boards. If you are working on a project where visual identification of switch states is important, consider the color contrast with your board.
Some switches feature clear ON/OFF markings, which can help with manual configuration. Choose a color that provides good contrast for your specific application.
Frequently Asked Questions
What is the difference between a 4-position and 8-position dip switch?
A 4-position dip switch has four individual switches, allowing for 16 possible binary states. An 8-position dip switch has eight switches, allowing for 256 possible states. The choice depends on the number of configuration options your circuit requires. Check your project specifications to determine the correct position count.
Are these dip switches compatible with Arduino and Raspberry Pi?
Yes, many of the listed switches are designed for compatibility with popular development boards like Arduino, ESP32, and Raspberry Pi. The 2.54mm pitch is a common standard in electronics. Ensure that the position count matches the number of pins you need to configure on your development board.
Can I use these dip switches on a breadboard?
Yes, the 2.54mm pitch is compatible with standard breadboards. You can plug the switches directly into the breadboard holes for prototyping. This is useful for testing circuits before soldering them onto a PCB. The slide-type design allows for easy manual configuration during testing.
What is the switching rating of these dip switches?
Most listed switches have a switching rating of 25mA DC 24V and a non-switching rating of 100mA DC 24V or 50V. This means they are suitable for low-power control applications. Do not use them to switch high-current loads, as this may damage the switches. Check the specific rating for each product before use.
