Selecting the right solid state relay depends on matching the input voltage to your controller and the output type to your load. Unlike mechanical relays, these modules use semiconductor components to switch power without physical contact, reducing wear and noise.
The options here range from micro-sized 1A units for hobbyist electronics to 40A industrial modules for temperature control. Key differences include whether the output is AC or DC, the current rating, and the physical form factor. Reviewing these specifications ensures the relay can handle the specific electrical demands of your project.
Our pick: BlueStars SSR-25DD 25A DC-DC Relay (Pack of 2). The BlueStars SSR-25DD handles DC outputs up to 200V, fitting applications that require DC-to-DC switching rather than AC.
Our 3 picks for different needs
1A Mini DC-DC Relay (10-Pack)
The 1A micro relay is ideal for ESP32 and Raspberry Pi boards where space and low current are the primary constraints.
Read the details
SSR-40DA 40A DC-AC Relay (3-Pack)
The 40A rating in this 3-pack suits heavier AC loads like industrial heaters or large motors controlled by a DC signal.
Read the details
BlueStars SSR-25DD 25A DC-DC Relay (Pack of 2)
The BlueStars SSR-25DD handles DC outputs up to 200V, fitting applications that require DC-to-DC switching rather than AC.
Read the detailsAll products, in detail
BlueStars SSR-25DD 25A DC-DC Relay (Pack of 2)
This BlueStars pack includes two SSR-25DD modules designed for DC-to-DC switching. The input accepts 3-32V DC while the output handles 5-200V DC at 25A. The metal back plate aids heat dissipation, and the unit includes a copper terminal lug for conductivity. It is suitable for applications requiring DC output control, such as specific heating or cooling systems.
The package includes detailed instructions for installation.
- DC 3-32V input and DC 5-200V output
- Pack of 2 with metal heat-dissipating back plate
SSR-40DA 40A DC-AC Relay (3-Pack)
This three-pack of SSR-40DA modules is rated for 40A at 250V AC output. The input is 3-32V DC, making it a DC-to-AC control device. The compact 62x45x24mm size fits standard mounting profiles. It is designed for use with PID thermostats and temperature controllers. The listing highlights resistance to corrosion, moisture, and dust, making it suitable for harsh industrial environments.
- 40A current rating with 24-380V AC output
- Includes 3 modules in the package
CG SSR-25DA 25A DC-AC Relay (2-Pack)
The CG SSR-25DA is a single-phase relay with a 25A rating. It accepts 3-32V DC input and switches 24-480V AC output. The package includes two mini bags of thermal grease to assist with temperature dissipation. The unit measures approximately 58x45x32mm and weighs 116g. It is intended for automatic process control and temperature management systems.
- 25A rating with 24-480V AC output range
- Includes thermal grease in the package
CG SSR-40DA 40A DC-AC Relay (2-Pack)
This CG module offers a higher 40A current capacity compared to the 25A variant. It features a 3-32V DC input and a 24-480V AC output. The physical dimensions are 58x45x32mm, and the unit weighs 116g. The package includes thermal grease for heat management. It is designed for applications requiring higher current switching in automatic control systems.
- 40A current rating with 24-480V AC output
- 58x45x32mm dimensions with plastic cover
CG SSR-25DD 25A DC-DC Relay (2-Pack)
The CG SSR-25DD is a DC-to-DC relay with a 25A rating. The input is 3-32V DC, and the output is specified as 5-220V DC in the features, though the title lists 5-240V DC. The unit measures 58x45x32mm and weighs 116g. It includes thermal grease for installation.
This model is suitable for DC load control in process automation.
- DC 3-32V input and DC 5-220V output
- 25A current rating with included thermal grease
1A Mini DC-DC Relay (10-Pack)
This slim, micro-sized relay is designed for low-current applications, with a maximum of 1A without a heatsink. It accepts 3-32V DC input and outputs 5-60V DC. The package contains 10 units, making it suitable for development boards like ESP32, Raspberry Pi, and Arduino. It uses optocoupler isolation for contactless operation.
The small form factor allows for dense PCB layouts.
- 1A maximum current rating without heatsink
- 10-pack of micro-sized DC-DC relays
HiLetgo SSR-25DA 25A DC-AC Relay (2-Pack)
The HiLetgo SSR-25DA is a 25A relay with a 250V AC output rating. It features a 3-32V DC input and an alloy heat sink. The control method is DC to AC. This two-pack is suitable for temperature control modules. The listing specifies the model and voltage parameters but does not include thermal grease in the description.
- 25A rating with 24-380V AC output
- Includes alloy heat sink
Coliao SSR-25DA 25A DC-AC Relay (4-Pack)
This Coliao pack contains four SSR-25DA modules. Each unit is rated for 25A at 250V AC with a 3-32V DC input. The dimensions are 62x45x24mm. The listing emphasizes suitability for harsh environments with resistance to corrosion and moisture. It is a bulk option for projects requiring multiple identical relay channels.
- 4-pack of 25A DC-AC relays
- 62x45x24mm compact module size
Head-to-Head Comparisons
CG SSR-25DA vs CG SSR-40DA: Current Capacity
Both CG relays share the same 3-32V DC input and 24-480V AC output range, but they differ in current handling. The SSR-25DA is rated for 25A, while the SSR-40DA handles 40A. If your load draws less than 25A, the 25DA is sufficient. For loads approaching or exceeding 25A, the 40DA provides the necessary capacity.
Both units measure 58x45x32mm and include thermal grease, so the physical footprint remains identical regardless of the current rating chosen.
SSR-40DA 3-Pack vs Coliao SSR-25DA 4-Pack
These two packs offer different quantities and current ratings. The first pack includes three 40A modules, while the Coliao pack includes four 25A modules. If you need four channels of control, the Coliao pack provides the quantity, but each channel is limited to 25A. If you need fewer channels but higher power per channel, the 40A pack is the better fit.
Both listings specify the module dimensions as 62x45x24mm.
1A Micro Relay vs HiLetgo 25A Relay
These two products serve vastly different scales. The 1A micro relay is a slim, contactless switch designed for logic-level control in development boards, with a 5-60V DC output. The HiLetgo SSR-25DA is a standard-sized module with a 25A rating and 24-380V AC output. The micro relay is for switching small sensors or LEDs, while the HiLetgo unit is for switching mains-powered devices.
Choosing between them depends entirely on whether you are controlling a microcontroller pin or a household appliance.
Buying Guide
Input Voltage Compatibility
All listed relays accept a 3-32V DC input, which is a standard range for most microcontrollers and industrial controllers. Ensure your control signal falls within this window. If you are using a 5V or 3.3V logic signal, these relays are compatible. If your control system outputs a different voltage, you may need to check if the relay can handle it, though the 3-32V range covers most common digital outputs.
This standardization simplifies integration with devices like Arduino or PLCs.
AC vs DC Output
Determine whether your load is AC or DC. Relays like the SSR-25DA and SSR-40DA are DC-to-AC, meaning they take a DC signal to switch an AC load. Relays like the SSR-25DD are DC-to-DC, switching DC loads. Using a DC-AC relay for a DC load, or vice versa, will not work.
Check your load's power type first. For example, a standard heater is AC, while a battery bank or DC motor is DC. This distinction is the most critical factor in selection.
Current Rating and Heatsinking
Match the relay's current rating to your load's draw. A 25A relay is suitable for loads up to 25A, while a 40A relay handles higher demands. The 1A micro relay is for very low current. Most standard relays require a heatsink to dissipate heat, especially at higher currents.
Some packages include thermal grease, which helps transfer heat from the relay to the heatsink. Ensure you have an appropriate heatsink for the size of the relay you choose, as the physical dimensions vary between models.
Form Factor and Mounting
Standard relays like the SSR-25DA and SSR-40DA have similar footprints, often around 58x45x32mm or 62x45x24mm. The micro relays are significantly smaller. Check the mounting holes and dimensions of your chassis or PCB. If you are replacing an existing relay, ensure the new one fits the same mounting profile.
The physical size affects how much space you need for heatsinks and wiring. Compact modules are better for dense control panels, while larger units may offer better heat dissipation surface area.
Frequently Asked Questions
Can I use a DC-AC relay to switch a DC load?
No, a DC-AC relay is designed to switch AC loads using a DC control signal. To switch a DC load, you need a DC-DC relay. Using the wrong type will result in no switching or potential damage. Always verify the output type of the relay matches the power type of your load.
Do these relays require a heatsink?
Most standard 25A and 40A relays generate heat and require a heatsink for continuous operation. The 1A micro relay may not require one at low currents, but the listing notes a 1A limit without a heatsink. Check the specific thermal requirements of your model and ensure adequate airflow or a mounted heatsink.
What is the difference between 25A and 40A relays?
The primary difference is the maximum current they can switch. A 25A relay handles loads up to 25 amps, while a 40A relay handles up to 40 amps. Choose the 40A model if your load draws more than 25A. Both types typically share the same input voltage range, so the choice is based on power capacity.
Are these relays suitable for temperature controllers?
Yes, many of these relays are specifically designed for use with PID thermostats and temperature controllers. They provide the fast, silent switching needed for precise temperature regulation. Ensure the relay's output voltage and current rating match the requirements of your heating or cooling element.
