Industrial Air Cylinders: 8 Options Compared for 2026

This post contains affiliate links. As an Amazon Associate we earn from qualifying purchases.

Product details come from Amazon listings. Compare the specifications that matter to you, and check the current price and availability on Amazon before buying. How we compare

Selecting the right industrial air cylinder depends on matching the bore and stroke to your specific automation task. Bore diameter determines the force output, while stroke length defines the travel distance.

This comparison covers eight options ranging from mini cylinders for tight spaces to long-stroke models for extended travel. Each unit is double-acting, ensuring consistent force in both directions. Review the specifications to find the configuration that fits your machinery.

AT A GLANCE

Our 3 picks for different needs

BAOMAIN Pneumatic Air Cylinder 2-1/2' Bore 19.69' Stroke SC63x500
04Long Travel Application

Baomain SC63x500 Air Cylinder

The 19.68 inch stroke on this 2-1/2 inch bore cylinder suits tasks requiring extended linear motion.

Read the details
BAOMAIN Mini Pneumatic Air Cylinder 5/8' Bore 0.4' Stroke CDJ2B10x10
05Confined Space Automation

Baomain CDJ2B10x10 Mini Cylinder

The 10mm bore and 20mm body diameter are engineered for tight and confined spaces in automation applications.

Read the details
HNJPC SC Series Pneumatic Cylinder 2-1/2 inch (63mm) Bore 4 inch (100mm) Stroke with Magnetic...
07Compact High Force

HNJPC SC63X100 Air Cylinder

The 2-1/2 inch bore with a short 4 inch stroke provides significant force in a compact footprint.

Read the details

All products, in detail

BAOMAIN Pneumatic Air Cylinder SC 63x300 2-1/2' Bore 12' Stroke with Clevis | Double Acting Air...
01

Baomain SC 63×300 Air Cylinder

This Baomain pneumatic cylinder features a 2-1/2 inch bore and a 12 inch stroke, making it suitable for applications requiring moderate travel distance. The double-acting design provides consistent force in both directions. It includes a clevis mounting bracket and a Y connector for flexible installation.

The aluminum alloy construction keeps the unit lightweight while maintaining durability for industrial automation tasks.

  • 2-1/2 inch bore with 12 inch stroke
  • Includes clevis mounting bracket and Y connector
HNJPC SC Air Cylinder 1-1/2 inch (40mm) Bore 4 inch (100mm) Stroke with Magnetic, Double Acting...
02

HNJPC SC40X100 Air Cylinder

The HNJPC SC40X100 is a compact double-acting cylinder with a 1-1/2 inch bore and 4 inch stroke. It is designed for industrial automation where space is limited but reliable linear motion is needed. The unit operates within a temperature range of -5 to 70 degrees Celsius and supports air pressures up to 145 PSI.

Its aluminum alloy body ensures corrosion resistance in various working environments.

  • 1-1/2 inch bore with 4 inch stroke
  • Operating temperature range of -5 to 70 degrees Celsius
BAOMAIN Pneumatic Air Cylinder 2-1/2' Bore 8' Stroke SC63x200 | Double Acting Air Cylinder, PT...
03

Baomain SC63x200 Air Cylinder

This Baomain model offers a 2-1/2 inch bore with an 8 inch stroke, providing a balance between force and travel length. The double-acting, single-rod design ensures consistent performance. It features an M16x1.5 threaded piston rod and a PT 3/8 air port for standardized connections. The integrated self-lubricating bearing supports maintenance-free operation in light industry and packaging applications.

  • 2-1/2 inch bore with 8 inch stroke
  • M16x1.5 threaded piston rod and PT 3/8 port
BAOMAIN Pneumatic Air Cylinder 2-1/2' Bore 19.69' Stroke SC63x500
04Long Travel Application

Baomain SC63x500 Air Cylinder

The Baomain SC63x500 provides a long 19.68 inch stroke with a 2-1/2 inch bore, ideal for applications requiring extended linear travel. The double-acting design maintains consistent force throughout the motion. It includes two push-in fittings for 8mm tubing, facilitating quick system integration. The high-strength aluminum alloy construction offers a lightweight yet durable solution for material handling and machinery.

  • 2-1/2 inch bore with 19.68 inch stroke
  • Includes two push-in fittings for 8mm tubing
BAOMAIN Mini Pneumatic Air Cylinder 5/8' Bore 0.4' Stroke CDJ2B10x10
05Confined Space Automation

Baomain CDJ2B10x10 Mini Cylinder

This mini pneumatic cylinder features a 10mm bore and 10mm stroke, engineered for tight and confined spaces. The compact 20mm body diameter allows for precise linear motion in dense automation setups. It is constructed from stainless steel for enhanced corrosion resistance. The double-acting design provides controlled pushing and pulling force, ensuring operational accuracy in small-scale industrial environments.

  • 10mm bore and 10mm stroke
  • Stainless steel construction with 20mm body diameter
HNJPC SC Air Cylinder 1-1/4 inch (32mm) Bore 10 inch (250mm) Stroke, Double Acting Aluminum...
06

HNJPC SC32X250 Air Cylinder

The HNJPC SC32X250 is a double-acting aluminum cylinder with a 1-1/4 inch bore and 10 inch stroke. It is designed for industrial automation tasks requiring moderate travel. The unit supports air pressures up to 145 PSI and operates within a temperature range of -5 to 70 degrees Celsius.

The PT1/8 threaded hole size ensures compatibility with standard pneumatic fittings for secure connections.

  • 1-1/4 inch bore with 10 inch stroke
  • PT1/8 threaded hole size for air connection
HNJPC SC Series Pneumatic Cylinder 2-1/2 inch (63mm) Bore 4 inch (100mm) Stroke with Magnetic...
07Compact High Force

HNJPC SC63X100 Air Cylinder

This HNJPC heavy-duty cylinder features a 2-1/2 inch bore and a 4 inch stroke, suitable for applications needing high force in a compact package. The double-acting design ensures reliable operation in both extension and retraction. It is built from aluminum alloy for durability and corrosion resistance.

The PT3/8 threaded hole size allows for standardized air supply connections in industrial settings.

  • 2-1/2 inch bore with 4 inch stroke
  • PT3/8 threaded hole size for air connection
BAOMAIN Pneumatic Air Cylinder 1-1/4' Bore 19.69' Stroke SC32x500
08

Baomain SC32x500 Air Cylinder

The Baomain SC32x500 offers a 1-1/4 inch bore with a long 19.68 inch stroke, ideal for extended travel applications. The double-acting, single-rod design provides consistent force. It features an M10X1.25 threaded piston rod and a PT 1/8 air port. The unit includes two push-in fittings for 6mm tubing, enabling easy installation into pneumatic systems for light industry and packaging.

  • 1-1/4 inch bore with 19.68 inch stroke
  • M10X1.25 threaded piston rod and PT 1/8 port

Head-to-Head Comparisons

Baomain SC 63×300 vs SC63x200: Stroke Length Choice

Both Baomain cylinders share a 2-1/2 inch bore, meaning they offer similar force capabilities. The primary difference is the stroke length. The SC 63×300 provides a 12 inch stroke, while the SC63x200 offers an 8 inch stroke. If your application requires the piston to travel further, the 300mm model is the appropriate choice.

For applications with limited space or shorter travel needs, the 200mm model is more compact. Both include mounting kits and fittings for easy installation.

HNJPC SC40X100 vs SC32X250: Bore and Stroke Tradeoff

These HNJPC cylinders differ in both bore and stroke. The SC40X100 has a larger 1-1/2 inch bore but a shorter 4 inch stroke. The SC32X250 has a smaller 1-1/4 inch bore but a longer 10 inch stroke. Choose the SC40X100 if you need higher force in a short distance.

Choose the SC32X250 if you need longer travel and can accommodate the slightly lower force. Both operate within the same temperature and pressure ranges, ensuring consistent performance in standard industrial environments.

Baomain SC63x500 vs SC32x500: Force vs Travel

Both Baomain models feature a long 19.68 inch stroke, making them suitable for extended travel applications. The key difference is the bore size. The SC63x500 has a 2-1/2 inch bore, providing higher force output. The SC32x500 has a 1-1/4 inch bore, offering lower force but a lighter weight.

If your application requires moving heavier loads over a long distance, the 63mm bore is the better fit. For lighter loads where weight is a concern, the 32mm bore is more appropriate.

Buying Guide

Matching Bore Size to Force Requirements

The bore diameter directly impacts the force the cylinder can generate. Larger bores, such as the 2-1/2 inch models, provide higher force for heavy-duty tasks. Smaller bores, like the 1-1/4 inch or 10mm mini cylinders, are suitable for lighter loads. Determine the force needed for your application and select a bore size that meets or exceeds that requirement.

Check the specific force ratings for each model to ensure compatibility with your machinery.

Selecting the Right Stroke Length

Stroke length determines how far the piston travels. Measure the required travel distance in your application and add a small margin for safety. A stroke that is too short will not complete the task, while a stroke that is too long may cause mechanical interference.

For example, the 12 inch stroke on the SC 63×300 is ideal for moderate travel, while the 19.68 inch stroke on the SC63x500 suits extended motion. Ensure the stroke fits within your available space.

Considering Mounting and Connection Types

Different cylinders come with various mounting options and port sizes. The Baomain SC 63×300 includes a clevis bracket, which allows for pivoting motion. Other models may have base or flange mounts. Check the port size, such as PT 3/8 or PT 1/8, to ensure it matches your existing pneumatic fittings.

If you are integrating with industrial tube fittings, verify that the included push-in fittings are compatible with your tubing diameter.

Evaluating Material and Environmental Factors

Most cylinders in this comparison are made from aluminum alloy, which is lightweight and corrosion-resistant. The Baomain mini cylinder is made from stainless steel, offering enhanced durability in harsh environments. Consider the operating temperature and pressure ranges. The HNJPC models specify a range of -5 to 70 degrees Celsius and up to 145 PSI.

Ensure these limits align with your working conditions to prevent premature wear or failure.

Frequently Asked Questions

What is the difference between double-acting and single-acting cylinders?

Double-acting cylinders use air pressure to extend and retract the piston, providing consistent force in both directions. Single-acting cylinders use air for one direction and a spring for the return. The Baomain and HNJPC SC series cylinders listed here feature double-acting designs, ensuring reliable control for industrial automation tasks.

How do I determine the correct bore size for my application?

Calculate the force required to move your load. Larger bores generate more force. For heavy loads, choose a 2-1/2 inch bore. For lighter loads, a 1-1/4 inch or 10mm bore may suffice. Always verify the force rating against your specific mechanical requirements.

Are these cylinders suitable for outdoor use?

The aluminum alloy construction offers corrosion resistance, making them suitable for various environments. However, check the specific operating temperature ranges. The HNJPC models are rated for -5 to 70 degrees Celsius. For extreme outdoor conditions, ensure the temperature and humidity levels fall within these specified limits.

Do these cylinders come with mounting hardware?

Some models include mounting hardware. The Baomain SC 63×300 comes with a clevis bracket and Y connector. Other models may require separate mounting brackets. Check the product description for included accessories to ensure you have the necessary hardware for installation.
